Schneider 140CPU67060 Modicon Quantum HSBY CPU

Product Description

The Schneider Electric Modicon Quantum 140CPU67060 is a high-availability Unity Hot Standby (HSBY) processor engineered for mission-critical automation systems requiring continuous operation and redundancy. Designed for dual-CPU architectures, it enables seamless switchover between primary and standby controllers, minimizing downtime in process control environments.

This processor integrates multimode fiber-optic Ethernet for high-speed synchronization between redundant PLCs and supports large-scale distributed I/O systems across multiple industrial networks.

Key Features and Capabilities

• Hot Standby redundancy with automatic CPU synchronization
• Multimode fiber-optic Ethernet link (up to 4 km) for primary/secondary PLC interconnection
• High processing performance at 266 MHz
• Extensive communication protocol support including Modbus, Modbus Plus, Ethernet TCP/IP, and Profibus DP
• Scalable architecture for large distributed I/O systems
• Designed exclusively for remote and distributed I/O (local I/O not supported in HSBY mode)

Technical Specifications

General Information

• Model: 140CPU67060
• Product Type: Unity Hot Standby Processor
• Platform: Modicon Quantum
• Processor Speed: 266 MHz
• Internal Memory: 512 KB RAM (data)
• Program Memory: Expandable up to 7 MB via PCMCIA
• File Storage: Expandable up to 8 MB via PCMCIA

System Architecture

• Local Racks: Up to 2
• Distributed I/O Stations: Up to 63
• Remote I/O (X80 over Ethernet): Up to 6 drops
• Discrete I/O Capacity:
  • Up to 8,000 inputs / 8,000 outputs per network
• Analog I/O Capacity:
  • Up to 500 inputs / 500 outputs per network

Communication Interfaces

• Integrated Ports:
  • 1 × Modbus Plus (SUB-D 9)
  • 1 × Modbus (RJ45)
  • 1 × USB
  • 1 × Fiber optic (MT-RJ) for Hot Standby link
• Supported Networks:
  • Ethernet TCP/IP
  • Modbus / Modbus ASCII (RS232/485)
  • Modbus Plus
  • Profibus DP
  • AS-Interface
• Maximum Connections:
  • 3 × Ethernet TCP/IP (local)
  • 3 × Modbus Plus (local)
  • 3 × Profibus DP (local)
  • 1 × USB
  • 2 × AS-Interface (distributed)

Performance

• Instruction Execution Speed:
  • 10.28 Kinst/ms (100% Boolean)
  • 10.07 Kinst/ms (mixed logic)
• System Overhead:
  • 0.2 ms (fast task)
  • 1 ms (master task)

Electrical Requirements

• Bus Current Consumption: 2500 mA

Indicators

• LED Indicators:
  • Ethernet activity (green)
  • Ethernet collision (red)

Hot Standby Operating Notes

• Local I/O is not supported in Hot Standby configurations
• Advanced task types (fast, interrupt, timer tasks) are restricted in HSBY mode
• Designed for deterministic cyclic master task execution

Applications

The 140CPU67060 is suitable for:

• Oil & gas processing systems
• Power generation and distribution
• Water and wastewater treatment plants
• Chemical and petrochemical facilities
• Large-scale manufacturing lines requiring zero downtime

FAQ

Q: What is the main advantage of this processor compared to standard CPUs? A: The key advantage is its Hot Standby capability, allowing redundant CPU operation with automatic failover, ensuring continuous system availability.

Q: Can local I/O modules be used with this processor? A: No, local I/O is not supported in Hot Standby mode. Only distributed and remote I/O configurations are allowed.

Q: What type of redundancy link is used between CPUs? A: A multimode fiber-optic Ethernet connection (MT-RJ) is used for high-speed synchronization between primary and standby processors.
