Product Overview
The 5541-693 is a high-availability control module within the Woodward MicroNet TMR platform, engineered for critical rotating machinery and power-generation control. Developed by Woodward, this module operates inside a triple-modular-redundant (TMR) architecture, where three independent control lanes execute identical logic in parallel and continuously vote on outputs to eliminate single-point failures.
Designed for uninterrupted operation, the 5541-693 is deployed in turbine governors, compressor control systems, and other safety-sensitive industrial processes where deterministic real-time performance and fault tolerance are mandatory.
System Function and Role
Within a MicroNet TMR control rack, the 5541-693 functions as a core digital control element responsible for executing high-integrity control logic while participating in lane-to-lane voting and diagnostics. Each control lane operates autonomously, allowing the system to sustain full functionality even if one lane is removed or fails.
The module supports continuous online self-testing, fault isolation, and seamless failover without process interruption, making it suitable for SIL-oriented and mission-critical applications.
Technical Specifications
General Characteristics
- Product Type: Triple-Modular-Redundant Digital Control Module
- Brand: Woodward
- Model: 5541-693
- Control Architecture: TMR (Three Independent Processing Lanes)
- Country of Manufacture: United States
Mechanical and Installation
- Mounting: Rack-installed in MicroNet TMR chassis
- Weight: 1.5 kg
- Cooling Method: Forced air via system chassis
Control and Performance
- Processing Mode: Deterministic real-time execution
- Redundancy Level: Full triple redundancy with voting logic
- Diagnostics: Continuous online health monitoring
- Fault Handling: Automatic lane isolation and system reconfiguration
- Availability: Designed for continuous 24/7 operation
Integration and Compatibility
The 5541-693 integrates directly with MicroNet TMR power supplies, communication modules, and I/O subsystems. In some system configurations, distributors classify this part number as a discrete I/O field interface when paired with terminal assemblies, reflecting its flexible deployment within the TMR ecosystem.
Typical Application Scenarios
- Gas turbine speed, load, and fuel control
- Steam turbine governor systems
- Compressor anti-surge and load-sharing control
- Generator control and power-plant automation
- High-availability industrial processes requiring redundant control
Frequently Asked Questions
Is the 5541-693 a safety-rated controller?
The module is designed for use in safety-critical architectures and supports SIL-oriented system designs when integrated with appropriate MicroNet TMR components and system engineering practices.
Can the system operate if one control lane fails?
Yes. The TMR architecture allows full operation with one failed or removed lane, maintaining control through two-out-of-three voting.
Is this module field-replaceable?
Yes. The 5541-693 supports online replacement depending on system configuration, minimizing downtime during maintenance.
