GE IC695CPL410 Rackless CPU Controller High Quality

Overview

The GE IC695CPL410 is a high-performance standalone CPU controller for PACSystems RX3i. It supports mission-critical industrial automation and process control. Moreover, it eliminates the need for a traditional backplane, enabling compact installation. Additionally, it provides powerful edge computing capabilities for advanced applications.

Technical Specifications

General

• Part Number: IC695CPL410
• Platform: PACSystems RX3i
• Processor: 1.2 GHz AMD G-series quad-core
• Operating System: VxWorks
• User Memory: 64 MB
• Program Block Capacity: Up to 768 blocks
• Maximum Block Size: 128 KB
• Instruction Speed: ≤ 0.15 µs per instruction
• Frame Rate: As fast as 3 ms
• Weight: 2.00 lbs (0.91 kg)

I/O and Communication

• I/O Capacity: Up to 32K discrete points, 32K analog words
• Ethernet Ports: 5 x RJ45 (supports up to 4 Ethernet LANs)
• Dedicated Linux Port: 1 port
• USB Ports: 2 x USB 3.0
• Serial Port: 1 x RJ45 COM (RS-232)
• Communication Protocols: OPC UA, Profinet IO, Modbus TCP/IP

Edge Computing and Storage

• PACEdge RAM: 2 GB
• PACEdge Storage: 50 GB SSD
• Features: PACEdge Linux co-processing, web HMI, SD card data logging

Power and Mounting

• Input Voltage Range: 18–30 VDC (24 VDC nominal)
• Maximum Power Consumption: 20 Watts
• Mounting Options: DIN rail or panel mount

Security and Redundancy

• Cybersecurity: TPM, secure boot, encrypted firmware
• Redundancy Support: Profinet System Redundancy (PNSR), Media Redundancy Protocol (MRP)

Compliance and Display

• Certifications: Marine ABS, DNV-GL, BV, LR
• Display: OLED
