GE IS200HSLAH1A High-Speed Serial Link Interface Module

Overview

The GE IS200HSLAH1A is a High-Speed Serial Link Interface Module. It enables fast fiber-optic communication between control processors and I/O modules. The module ensures synchronized data exchange in distributed turbine control architectures. It integrates EX2100, Mark VI, and Mark VIe systems efficiently. The board mounts directly onto IS200MVRCH1A to form a complete IS210MVRCH1A assembly. This module supports connections with HMI, LS2100, LS2100e, and other GE platforms using a dedicated HSSL cable. Its FPGA-based logic guarantees reliable high-speed data routing in industrial environments.

Technical Specifications

• Model Number: IS200HSLAH1A
• Function: High-Speed Serial Link Interface Module
• Series Compatibility: EX2100, EX2100e, Mark VI, Mark VIe, LS2100, LS2100e
• Form Factor: CompactPCI
• Ports: 1 Ethernet port for HSSL, 3 rear ports for MVRC
• Fiber-Optic Transceivers: 2 ports using HFBR-5961xxZ optical components
• Data Management: FPGA-based protocol logic and data routing
• Memory: SDRAM and Flash
• Input Voltage: 24 V DC nominal
• Power Consumption: 8.5 W
• Operating Temperature: 0°C to +60°C
• Storage Temperature: –40°C to +85°C
• Dimensions: 14.7 × 5.15 × 11.4 cm
• ​Weight: 0.6 kg
• Environmental Protection: Conformal coating for humidity and contaminant resistance
• LED Indicators: RUN (green), STATUS (yellow), FAIL (red)
• Mounting: Directly mounts to MVRC board; drilled for secure installation
• Cable Type: Yellow HSSL cable
• Abbreviation: C Core HSLA
• Key Feature: FPGA-based high-speed data routing
