The 3300 XL 11 mm Proximity Transducer System is designed for non-contacting vibration and displacement measurements on fluid film bearing machines. It offers a 3.94 V/mm (100 mV/mil) output, providing accurate data for various applications. The system consists of the following components:
- 3300 XL 11 mm Probe: The large 11 mm probe enables a longer linear range compared to the standard 3300 XL 8 mm Transducer System. This feature makes it suitable for specific applications that require extended measurement capabilities.
- 3300 XL 11 mm Extension Cable: A high-quality extension cable that ensures reliable and efficient signal transmission between the probe and the Proximitor Sensor.
- 3300 XL 11 mm Proximitor Sensor: The key component of the system, designed to replace the 7200-series 11 mm and 14 mm Transducer Systems. It offers enhanced performance and compatibility.
Applications:
The 3300 XL 11 mm Proximity Transducer System is primarily used in the following applications where its longer linear range proves beneficial:
- Axial (Thrust) Position Measurements
- Ramp Differential Expansion Measurements on Steam Turbines
- Rod Position or Rod Drop Measurements on Reciprocating Compressors
- Tachometer and Zero Speed Measurements
- Phase Reference (Keyphasor) Signals
Upgrading and Compatibility:
When upgrading from the 7200-series system to the 3300 XL 11 mm system, it's essential to replace every component with the corresponding 3300 XL 11 mm components. Moreover, the monitoring system must be updated to accommodate the new transducer system.
- For those using a 3500 Monitoring System, an updated version of the configuration software that includes the 3300 XL 11 mm Transducer System as a compatible option is required.
- Existing 3300 Monitoring Systems may need modifications to support the upgraded system. For assistance with the upgrade process, please contact your local sales and service representative.
The 3300 XL 11 mm Proximity Transducer System is a reliable and advanced solution for various industrial applications, providing accurate and extended measurement capabilities for fluid film bearing machines.
