Schneider Electric 140NRP31200 Quantum Fibre Converter

17 disponibles en stock

Manufacturer: Schneider
Product No.: 140NRP31200
Country of origin: France
Product Type: Quantum Fibre Converter
Condition: Completamente nuevo
Payment: T/T, Western Union
Weight: 0.55 kg
Shipping port: Xiamen
Warranty: 12 meses

Descripción
Reviews
Envío y pago

Overview

The Schneider Electric 140NRP31200 is a multi-mode Ethernet fibre converter developed for the Modicon Quantum automation platform. Designed for industrial Ethernet communication systems, this module converts standard copper Ethernet signals into fiber-optic transmission for improved network distance, electromagnetic immunity, and communication reliability.

The converter supports dual-channel 100 Mbps Ethernet communication with LC-type fiber optic connections and RJ45 copper interfaces. Its compact design and industrial-grade construction make it suitable for process control systems, distributed automation networks, and plant-wide communication infrastructures.

The 140NRP31200 module is engineered for stable operation in harsh industrial environments and supports long-distance fiber communication between network devices and PLC systems.

Key Features

Dual-channel industrial Ethernet fibre converter
Supports 100 Mbps Ethernet communication
Multi-mode fiber optic transmission
Two LC fiber optic ports
Two RJ45 Ethernet ports
Extended communication distance up to 3000 meters
High resistance to electrical interference and signal noise
Compact module for Modicon Quantum systems
LED diagnostics for link and communication monitoring
Industrial operating temperature range
CE certified industrial communication device

Technical Specifications

Parameter	Specification
Manufacturer	Schneider Electric
Product Series	Modicon Quantum
Product Type	Ethernet Fibre Converter
Model	140NRP31200
Fiber Type	Multi-Mode
Ethernet Speed	100 Mbps
Fiber Connector	2 x LC
Copper Ethernet Ports	2 x RJ45
Communication Channels	2 Channels
Operating Wavelength	1310 nm
Maximum Fiber Distance	2000 m (50/125 µm)
Maximum Fiber Distance	3000 m (62.5/125 µm)
Receiver Sensitivity	-30 dBm
Detected Silence	-45 dBm
Rise/Fall Time	3 ns
Bus Current Requirement	1000 mA
Inrush Current	1 A at 5 VDC
Power Dissipation	5 W
Housing Material	Polycarbonate (PC)
Status Indicators	RDY, ERR, STS1, FX1 ACT, STS2, FX2 ACT
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Relative Humidity	0% to 95% non-condensing
Operating Altitude	Up to 2000 m
Protection Certifications	CE, TÜV, C-Tick
Compliance Standards	UL 508, CSA C22.2 No 142, FM Class 1 Div 2
Weight	0.55 kg

Communication and Network Performance

The 140NRP31200 fibre converter is designed to extend Ethernet communication across industrial facilities where long cable runs or electrically noisy environments make copper Ethernet impractical.

By converting Ethernet signals from RJ45 copper to LC multi-mode fiber, the module helps maintain communication integrity in:

Manufacturing plants
Process automation systems
Water treatment facilities
Power generation sites
Remote I/O installations
High-interference industrial zones

LED Diagnostic Indicators

Integrated front-panel LEDs provide fast visual diagnostics for network status and module health:

RDY: Module operational status
ERR: Internal fault indication
STS1 / STS2: Fiber link status
FX1 ACT / FX2 ACT: Channel communication activity

These indicators simplify troubleshooting during commissioning and maintenance.

Physical Characteristics

Dimension	Value
Width	40.34 mm
Height	250 mm
Depth	103.85 mm

Typical Applications

Ethernet-to-fiber conversion
Industrial network extension
PLC communication infrastructure
Fiber optic backbone systems
Modicon Quantum network installations
High-noise industrial Ethernet environments

FAQ

What type of fiber does the 140NRP31200 support?

The module supports multi-mode fiber optic communication using LC connectors.

How many Ethernet channels are available?

The converter supports two independent Ethernet fiber channels.

Can this module be used in harsh industrial environments?

Yes. The module is designed for industrial applications and complies with UL, CSA, FM, and CE standards.

What is the maximum communication distance?

The transmission distance reaches up to 3000 meters depending on the fiber cable specification used.

Does the module support standard RJ45 Ethernet connections?

Yes. It includes two RJ45 Ethernet ports for copper network integration.
