ABB 1MRK002246-BC Relion 670 Power Supply Module

11 in stock

Manufacturer: ABB
Product No.: 1MRK002246-BC
Country of origin: Sweden
Product Type: Relion 670 Power Supply Module
Condition: Brand New
Payment: T/T, Western Union
Weight: 0.38 kg
Dimensions: 74 mm x 370 mm x 361 mm
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

The ABB 1MRK002246-BC, also cataloged as the 1MRK002246-BC Power Supply Module, provides regulated DC power for internal processing, I/O, and communication electronics within ABB Relion 670 protection and control system rack assemblies. It accepts 198-264 VAC auxiliary input and provides a 5 VDC output at up to 10 A.

Hardware Specifications

Parameter	Specification
Model	1MRK002246-BC
Brand	ABB
Module Type	Power Supply Board / PSM
System Series	Relion 670
Application	Internal power supply for protection and control relay electronics
Input Voltage	198-264 VAC
Nominal Input	230 VAC
Output Voltage	5 VDC
Output Voltage Range	4.5-5.5 VDC
Output Current	10 A
Efficiency	Approx. 85%
Dimensions	74 mm x 370 mm x 361 mm
Weight	0.38 kg
Origin	Sweden

ABB Relion 670 Power Supply Characteristics

The 1MRK002246-BC converts the rack auxiliary AC supply into regulated low-voltage DC power for internal electronic circuits. The specified 5 VDC output operates within a 4.5-5.5 VDC range and supports a maximum output current of 10 A.

The module is associated with ABB Relion 670 series protection platforms, including RED 670, RET 670, and REC 670. Its electrical interface is defined by the 198-264 VAC input range and regulated low-voltage output rather than by external field signal processing.

Frequently Asked Questions

Q: What output voltage does the 1MRK002246-BC provide?
A: The specified nominal output is 5 VDC, with an output range of 4.5-5.5 VDC.

Q: What is the maximum specified output current?
A: The module is specified for an output current of 10 A.

Q: Is hot-swap operation specified for this module?
A: Hot-swap capability is not stated in the supplied technical data. Rack removal or replacement should therefore follow the applicable Relion 670 hardware service procedure.

Field Installation Guidelines

Install the module only in the designated Relion 670 rack position and verify that the rack assembly is isolated from the auxiliary supply before physical replacement.

Confirm that the available auxiliary voltage falls within the specified 198-264 VAC input range. AC supply conductors should be routed separately from low-level protection, measurement, and communication wiring where the rack installation permits.

Verify module seating and connector engagement before energization. Do not apply external voltage to the 5 VDC output interface. Shielding and protective-earth connections should follow the Relion 670 rack wiring documentation and the applicable substation installation standard.

After energization, verify the presence of the specified DC output before returning connected processing, I/O, and communication electronics to normal operation.
