ABB 1MRK002305-AAr01 IRIG-B Time Synchronization Module

13 in stock

Manufacturer: ABB
Product No.: 1MRK002305-AAr01
Country of origin: Sweden
Product Type: IRIG-B Time Synchronization Module
Condition: Brand New
Payment: T/T, Western Union
Weight: 1.52 kg
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

Configured for IRIG-B time-code decoding in ABB Relion 670/650 protection and control IEDs, the ABB 1MRK002305-AAr01 (1MRK002305 IRIG-B Time Synchronization Module) provides time-reference processing through the IED backplane. The module accepts IRIG-B signals from external master clocks or GPS receivers and distributes synchronized timing for sequence-of-events recording and fault analysis.

Hardware Specifications

Parameter	Specification
Model	1MRK002305-AAr01
Base Model	1MRK002305
Brand	ABB
Product Type	IRIG-B Time Synchronization Module
Primary Function	IRIG-B signal decoding and system clock synchronization
Supported Time Formats	IRIG-B formats including 001, 002, and 100
Input Interface	BNC coaxial connector / optocoupler input, depending on backplane configuration
System Compatibility	ABB Relion 670 / 650 Series protection and control IEDs
System Application	Substation Automation Systems
Operating Voltage	24 V DC via backplane
Operating Temp	-20 deg C to +60 deg C
Storage Temp	-40 deg C to +85 deg C
Relative Humidity	5% to 95%, non-condensing
Enclosure / Protection Rating	IP20 when installed inside the IED rack enclosure
Country of Origin	Sweden

ABB Relion IRIG-B Time Synchronization

The module decodes external IRIG-B time codes and converts received timing information into an IED system time reference.
It supports IRIG-B formats 001, 002, and 100 according to the supplied technical information.
The input interface may use a BNC coaxial connection or optocoupler input, depending on backplane configuration.
The 24 V DC operating supply is provided through the IED backplane rather than a separate field supply.
For firmware maintenance, compatibility should be checked against the installed Relion IED hardware and applicable software release.

Frequently Asked Questions (FAQ)

Q: What signal does the 1MRK002305-AAr01 process?
A: It processes IRIG-B time-code signals supplied by an external master clock or GPS-based timing source.

Q: How is the module powered inside the IED?
A: The supplied data specifies a 24 V DC operating supply delivered through the IED backplane.

Q: Can the module be installed as an external standalone timing device?
A: The supplied data identifies it as hardware for ABB Relion 670/650 IEDs, with IP20 protection when installed inside the IED rack enclosure.

Field Installation Guidelines

Install the module only in the specified ABB Relion IED hardware configuration and compatible backplane position.
Verify the installed IED type, module position, connector arrangement, and applicable ABB hardware documentation before energization.
Route IRIG-B coaxial wiring separately from high-voltage, switching, and high-current conductors where practical.
Maintain proper cable shielding and terminate the shield according to the installed IED grounding scheme.
Avoid ground loops when connecting the external master clock or GPS receiver to the IED timing input.
Confirm the IRIG-B source format before commissioning, particularly when multiple time-code formats are available.
Verify the received time reference after installation using the IED diagnostic or time-synchronization status functions.
Do not assume compatibility from the part number alone when replacing modules across different Relion hardware revisions.
