ABB DIS0006 2RAA005802A0003G Digital Input Module

Overview

The DIS0006 2RAA005802A0003G Digital Input Module offers precise and reliable digital signal acquisition for ABB’s 615 series protection relays. ABB engineers this module in Switzerland with strict quality control. It weighs about 0.3 kg and installs quickly on a DIN rail. The IP20 protection ensures safe operation in indoor electrical panels. This module captures external digital signals such as switch positions and sensor outputs with speed and accuracy. Its 12-month warranty supports long-term operational reliability.

Technical Specifications

Input Specifications

• Input Channels: 12 digital inputs
• Input Voltage Range: 24 to 250 V DC
• Nominal Input Current: 2 mA
• Response Time: Typically 5 ms

Electrical Characteristics

• Power Consumption: Maximum 1.5 W
• Isolation: 2 kV AC between inputs and system

Environmental Conditions

• Operating Temperature: –25°C to +70°C
• Storage Temperature: –40°C to +85°C
• Humidity: 5% to 95% (non-condensing)

Standards & Certifications

• EMC Immunity: IEC 61000-4-2 (8 kV)
• Vibration Resistance: 2 G (10–150 Hz)
• Shock Resistance: 15 G for 11 ms
