ABB DO815 3BSE013258R1 S800 I/O Digital Output Module

Low stock: 10 left

Manufacturer: ABB
Product No.: DO815
Country of origin: Sweden
Product Type: S800 I/O Digital Output Module
Condition: Brand New
Payment: T/T, Western Union
Weight: 0.2 kg
Dimensions: 45 mm W x 102 mm D x 119 mm H
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

Configured for 24 VDC current sourcing output control in the ABB S800 I/O system, the ABB DO815 3BSE013258R1 (DO815 Digital Output Module) provides direct physical/electrical execution through eight protected high side driver output channels.

Hardware Specifications

Parameter	Specification
Model	DO815
Brand	ABB
Origin	Sweden
Weight	0.2 kg
Dimensions	45 mm W x 102 mm D x 119 mm H
Operating Temp	0 to +55 deg C
Power Consumption	Typ. 4 W
Product Type	Digital Output Module
Series	S800 I/O
Article Number	3BSE013258R1
Signal Specification	24 VDC (10 to 32 VDC), 2 A
Number of Channels	8
Signal Type	High side driver, current limiting
Output Current	Maximum continuous 2 A @ 24 V
Output Voltage Range	10 to 30 V
Isolation	Two individually isolated groups of 4 channels
Output Protection	Short circuit, overload, open load detection
Modulebus Current Consumption	Typ. 120 mA, Max. 150 mA @ +5 V
External +24 VDC Consumption	0
Maximum Field Cable Length	600 meters
Rated Insulation Voltage	50 V
Dielectric Test Voltage	500 VAC
Protection Class	IP20 according to IEC 60529
MTU Compatibility	TU810, TU812, TU814, TU830

S800 I/O High Side Output Protection and Diagnostics

The DO815 uses eight 24 VDC current sourcing output channels implemented with protected high side drivers. Each channel integrates short circuit protection, overload protection, open load detection during active output state, EMC protection components, inductive load suppression, and optical isolation.

The output channels are arranged into two isolated groups containing four channels each. The module provides output status LEDs, channel error flags, and supervision functions for short circuit, overload, undervoltage, and open load conditions.

The ABB S800 I/O module communication behavior includes OSP (Output Set as Predetermined) handling, which transfers outputs to configured states when communication errors occur. Two output fault handling modes are supported: automatic reset mode and fault latching mode.

Frequently Asked Questions

Q: Does the DO815 support redundant output operation?
A: No. The DO815 module specification does not include output redundancy functionality.

Q: What type of output driver is used in the DO815?
A: The module uses high side driver outputs with current limiting and protection against short circuit and overload conditions.

Q: Which MTU units are compatible with the DO815?
A: The DO815 is compatible with ABB S800 I/O MTU units including TU810, TU812, TU814, and TU830.

Field Installation Guidelines

Install the DO815 module on the ABB S800 I/O mounting arrangement using the specified MTU configuration and approved connector accessories. Field wiring should maintain separation between signal circuits and high-energy conductors to reduce electrical interference.

Connect protective earth and cable shielding according to the cabinet grounding design. Verify output polarity before energizing field devices. Inductive loads should use appropriate suppression methods to prevent switching transients from affecting connected circuits.

Check channel status LEDs after installation to confirm normal RUN indication and verify that output fault diagnostics remain inactive during commissioning.
