ABB DSTD 150A 57160001-UH Advant Master Termination Unit

20 in stock

Manufacturer: ABB
Product No.: DSTD150A
Country of origin: Sweden
Product Type: Advant Master Termination Unit
Condition: Brand New
Payment: T/T, Western Union
Weight: 0.36 kg
Dimensions: 153 mm x 36 mm x 209.7 mm
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

Configured for high-density physical signal interfacing in Advant Master Process Control System networks, the ABB DSTD 150A (DSTD 150A Module Termination Unit) provides direct physical/electrical execution. It handles up to 32 digital input channels with a maximum operating voltage threshold of 60 V. Designed for seamless system integration, the unit links field discrete wiring directly to the process control backplane logic.

Hardware Specifications

Parameter	Specification
Model	DSTD 150A
Product ID	57160001-UH
Exchange Catalog ID	EXC57160001-UH
Brand	ABB
Origin	Sweden
Product Type	Module Termination Unit
Channel Density	32 Channels (Digital Input)
Voltage Limits	Max 60 V
Weight	0.36 kg
Dimensions (D x H x W)	153 mm x 36 mm x 209.7 mm
Operating Temp	Standard Industrial Limits
Power Consumption	Passive Termination (System Bus Powered)
Mounting Screws Kit	3BSE021202R1
Customs Tariff / HS Code	85389091 / 853890

Backplane Bus Communication Velocity & Deterministic Routing

The DSTD 150A features high-integrity signal routing designed to match backplane bus communication velocity and deterministic network synchronization across Advant Master platforms. Operating as a 32-channel termination module, it maintains strict channel-to-channel isolation and low latency during high-density I/O scan cycles. The firmware flash compatibility and physical trace layouts prevent signal crosstalk, ensuring deterministic I/O density scaling and uncorrupted digital state transmission to the host CPU under heavy electrical noise profiles.

Frequently Asked Questions

Q: What is the maximum voltage rating for discrete inputs on the DSTD 150A?

A: The connection unit is rated for a maximum potential of 60 V across its 32 digital input channels.

Q: Is the DSTD 150A connection unit supplied with mounting hardware?

A: Mounting screws are ordered separately under the dedicated mounting screws kit part number 3BSE021202R1.

Q: What system platform utilizes the DSTD 150A connection unit?

A: The unit is specifically manufactured for integration within the ABB Advant Master Process Control System framework.

Field Installation Guidelines

Ensure all field power sources supplying the 60 V digital input loops are de-energized prior to wire insertion or removal. Mount the DSTD 150A securely using the specified mounting screws kit (3BSE021202R1) to maintain chassis grounding integrity. Fasten all field signal conductors tightly to the terminal blocks to prevent intermittent contact resistance. Maintain strict separation between low-voltage field signal cables and high-voltage AC power lines within field raceways to eliminate electromagnetic interference. Verify ground continuity across the termination frame prior to system power restoration.

Payment: T/T, Western Union.

Shipping port: Xiamen.

Lead time: Typically 1–3 working days after payment confirmation (subject to stock).

Worldwide delivery: We ship industrial automation parts to customers around the world. Freight is quoted with your RFQ.
