ABB NTDI01 Digital I/O Termination Unit

20 in stock

Manufacturer: ABB
Product No.: NTDI01
Country of origin: Sweden
Product Type: Digital I/O Termination Unit
Condition: Brand New
Payment: T/T, Western Union
Weight: 0.5 kg
Dimensions: 78.74 mm W x 233.68 mm H x 213.36 mm D
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

The ABB NTDI01, also cataloged as the NTDI01 Digital I/O Termination Unit, provides the termination interface for DSI, DSO, DSM, SET, SED, ASO, HSS, FCS, NKTU, NKST, and NKSD system assemblies.

Hardware Specifications

Parameter	Specification
Model	NTDI01
Brand	ABB
Product Type	Module Termination Unit
Catalog Description	Digital I/O TU
Compatible Assemblies	DSI, DSO, DSM, SET, SED, ASO, HSS, FCS, NKTU, NKST, NKSD
Dimensions	78.74 mm W x 233.68 mm H x 213.36 mm D
WEEE Category	5 - Small Equipment
Batteries	0

ABB Digital I/O Termination Interface

The NTDI01 is identified by ABB as a Digital I/O TU and as a Module_Termination_Unit. Its documented system compatibility covers DSI, DSO, DSM, SET, SED, ASO, HSS, FCS, NKTU, NKST, and NKSD assemblies. The supplied data does not define channel count, terminal voltage, current loading, isolation characteristics, or backplane communication parameters, so these values should be verified against the associated system documentation before wiring.

Frequently Asked Questions (FAQ)

Q: Which ABB assemblies are specified for use with the NTDI01?
A: ABB lists DSI, DSO, DSM, SET, SED, ASO, HSS, FCS, NKTU, NKST, and NKSD.

Q: Does the supplied specification define the NTDI01 operating temperature?
A: No. The supplied ABB data identifies environmental and WEEE information but does not specify an operating temperature range.

Q: Does the supplied data specify electrical power consumption?
A: No. Power consumption is not stated in the provided product information.

Field Installation Guidelines

Install the NTDI01 according to the mechanical and electrical documentation for the associated ABB assembly. Verify the mounting position and available clearance using the stated dimensions of 78.74 mm x 233.68 mm x 213.36 mm.

Confirm terminal assignments and field wiring against the applicable DSI, DSO, DSM, SET, SED, ASO, HSS, FCS, NKTU, NKST, or NKSD documentation before applying power. Keep digital I/O wiring separated from high-current power conductors where required by the installation standard. Cable shields should be terminated according to the system grounding scheme, with shield routing arranged to avoid unintended ground loops.

Do not infer operating temperature, electrical loading, isolation, or signal ratings from the termination-unit designation alone.
