ABB TP830 3BSE018114R1 Module Termination Unit

Regular price: $152.01
Regular price: ~~$300.00~~
Sale price: $152.01
Unit price: per

14 in stock

Manufacturer: ABB
Product No.: TP830 3BSE018114R1
Country of origin: Sweden
Product Type: Module Termination Unit
Condition: Brand New
Payment: T/T, Western Union
Weight: 0.234 kg
Dimensions: 119 mm W x 189 mm H x 48 mm D
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

The ABB TP830 3BSE018114R1, also cataloged as the TP830 Module Termination Unit, operates as a dedicated hardware component for PM8xx processor module baseplate connection within ABB automation system platforms. The unit provides the mechanical mounting structure and electrical termination interface for processor module installation.

Hardware Specifications

Parameter	Specification
Model	TP830 3BSE018114R1
Brand	ABB
Origin	Sweden
Weight	0.234 kg
Dimensions	119 mm W x 189 mm H x 48 mm D
Product Type	Module Termination Unit
Compatible Module	PM8xx Processor Modules
ABB Type Designation	TP830
Width	115 mm
Product ID	3BSE018114R1

PLC Backplane Interface and Module Mounting

The ABB TP830 is designed as a baseplate assembly for PM8xx processor modules. The unit provides the mechanical support structure and connection interface required for processor module installation within ABB control system hardware configurations.

The module termination design maintains the physical alignment between processor modules and the associated system connections. Installation requires correct module positioning, connector engagement, and adherence to ABB cabinet wiring practices.

Frequently Asked Questions

Q: What processor modules are compatible with the ABB TP830 baseplate?
A: The TP830 is specified as a baseplate for ABB PM8xx processor modules.

Q: Does the TP830 require an external power supply connection?
A: The provided technical data does not specify an independent power supply requirement for the TP830 baseplate.

Q: Can the TP830 be installed without checking connector alignment?
A: No. Mechanical positioning and connector alignment must be verified before module insertion to prevent damage to the interface contacts.

Field Installation Guidelines

Install the ABB TP830 on the designated control cabinet mounting structure according to ABB system installation procedures. Verify mechanical fixation, module seating, and connector engagement before applying system power.

Signal and communication wiring should be routed separately from high-voltage power conductors where required by site electrical standards. Protective grounding and cabinet bonding should follow the applicable industrial control panel requirements.

Maintain sufficient clearance for processor module insertion and removal. Inspect connector surfaces before installation and avoid applying mechanical force outside the specified mounting direction.

Payment: T/T, Western Union.

Shipping port: Xiamen.

Lead time: Typically 1–3 working days after payment confirmation (subject to stock).

Worldwide delivery: We ship industrial automation parts to customers around the world. Freight is quoted with your RFQ.
