ABB TU710F 3BDH000398R0001 Terminal Block Brand New

13 in stock

Manufacturer: ABB
Product No.: TU710F-3BDH000398R0001
Product Type: Terminal Block
Condition: Brand New
Payment: T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

Overview

The TU 709F/710F terminal block functions as a base for the CI 741F PROFIBUS communication interface. Designed for handling 24 V I/O signals, it ensures reliable power distribution and grounding in industrial automation systems. The terminal block features a spring-type design for secure connections, making it highly durable and resistant to vibration. It is ideal for use in control panels and machinery where robust electrical connections are required.

Technical Specifications

Article Number: 3BDH000398R0001
Signal Specification: PROFIBUS
Mechanics: S700 Series
Terminal Type: Spring-type terminals

Electrical Characteristics:

Load Current: 10 A
Common Mode Voltage Input: 24 V DC
Supported Wire Size: 0.08 … 2.5 mm²

Internal Connections:

Terminals 2.8 and 3.8: Supply UP = +24 V DC
Terminals 2.9 to 4.9: Connect to ZP = 0 V (reference potential)

Environmental and Safety Compliance:

CE Mark: Yes
Electrical Safety Standards: EN 50178, IEC 61131-2, UL 61010-1, UL 61010-2-201
Hazardous Location Rating: cULus Class 1 Div 2
Protection Rating: IP20
RoHS Compliance: Directive 2011/65/EU
WEEE Compliance: Directive 2012/19/EU

Mechanical Dimensions:

Width: 68 mm
Depth: 30 mm
Height: 135 mm
Weight: 0.19 kg
