Overview
The DO216 is a 16-channel digital output module from Bachmann’s M200 series. It allows the M1 automation system to control relays, lamps, and valves with high speed and reliability. Each output supports up to 2.5 A at 24 V DC. The module includes advanced channel-to-channel isolation, high-performance noise filtering, and LED indicators for status monitoring. Its compact DIN rail design suits demanding industrial environments, while integrated diagnostics detect short circuits, cable breaks, and overloads.
Technical Specifications
| Feature | Details |
|---|---|
| Model | DO216 |
| Type | Digital Output Module |
| Channels | 16 digital outputs |
| Output Voltage Range | 18 V DC to 34 V DC |
| Input Voltage Range | 15 V DC to 34 V DC |
| Max Total Current | 12 A |
| Max Current per Channel | Up to 2.5 A at 24 V DC |
| Isolation | Channel-to-channel and system isolation |
| Diagnostics | Short-circuit, cable break, and overload detection |
| Filtering | High-performance noise reduction |
| Mounting | DIN rail compatible |
| Weight | 0.6 kg |
