Bently Nevada 3300/03-01-03 System Monitor Module Brand New

18 in stock

Manufacturer: Bently Nevada
Product No.: 3300/03-01-03
Country of origin: USA
Product Type: System Monitor Module
Condition: Brand New
Payment: T/T, Western Union
Weight: 0.9 kg
Dimensions: 5.7 x 20.3 x 33.0 cm
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

Overview

The Bently Nevada 3300/03-01-03 is a System Monitor Module in the 3300 Series. It installs in a 3300 rack and serves as the central control unit. The module distributes power, manages Keyphasor signals, and coordinates alarms. It provides Serial Data Interface (SDI) and Dynamic Data Interface (DDI) for integration. This module supports alarm acknowledgement, system inhibit, and Keyphasor termination functions.

Technical Specifications

Model Breakdown

3300/03: System Monitor module
-01: Standard configuration
-03: Basic to DDI Upgrade option

General

Function: System Monitor for 3300 Series Rack
Rack Space: One rack position next to the power supply
Weight: 0.9 kg
Dimensions: 5.7 x 20.3 x 33.0 cm

Power

Consumption: 2 W (4.6 W with interfaces)
Supply Voltages: +23.65 VDC, +7.5 VDC, +5 VDC, -7.5 VDC

Inputs and Signals

Keyphasor Signals: Up to four proximity probe inputs
Frequency Range: 60 to 30,000 rpm
Amplitude: Minimum 0.5 V peak-to-peak
DC Signal Range: 0 to -24 V

Communication Interfaces

RS232: 150 baud to 19.2 k baud, 30 m maximum
RS422: 150 baud to 19.2 k baud (SDI), up to 38.4 k baud (DDI), 1200 m maximum

Controls

Front Panel: Up/Down alarm setpoints, RESET button
Rear Panel: Rack Inhibit, Trip Multiply, Alarm Reset terminals

Environmental Limits

Operating Temperature: 0°C to +65°C
Storage Temperature: -40°C to +85°C
Relative Humidity: Up to 95%, non-condensing
