GE IC695ECM850 Ethernet Communication Module In Stock

Overview

The GE IC695ECM850 is a high-performance IEC 61850 Ethernet Communication Module. It integrates seamlessly with PACSystems RX3i controllers. The module supports both copper and fiber media through dual RJ-45 and SFP ports. It enables fast, reliable communication between industrial devices on IEC 61850 networks. With hot-swappable capability and configurable update rates, it ensures minimal downtime and optimal flexibility. This module is ideal for power automation and utility applications requiring high-speed, standardized communication.

Technical Specifications

• Model: IC695ECM850
• Product Type: Ethernet Communication Module
• Supported Media: Copper, Single-mode/Multi-mode Fiber
• Switched Ports: 4 (2 x RJ-45, 2 x SFP cages)
• Additional Port: 1 x Micro USB for communication
• Bus Type: Universal Backplane (PCI Bus)
• Bus Speed: 10/100/1000 Mbps
• I/O Update Rate: Configurable from 100 ms to 64 seconds
• Maximum I/O Memory: 12,072 points and 20,000 events
• Supported Devices: Up to 32 IEC 61850 devices
• Max Modules per RX3i CPU: 4
• IP Addresses per Module: 1
• MAC Addresses per Module: 5
• Hot-Swappable: Yes
• SNTP Support: Yes
• Power Consumption (3.3V): 0.5A (no SFP), up to 1.2A (2 SFPs)
• Power Consumption (5V): Up to 1.5A
• Operating Temperature: 0°C to 60°C
• Weight: 1.00 lbs
• Certifications: IEC 61850 compliant
