GE Multilin 489-P1-LO-A20-E Motor Management Relay

Overview

The GE Multilin 489-P1-LO-A20-E is a motor management relay. It protects, monitors, and controls medium-sized AC motors. Engineers use it in demanding industrial automation systems.

Technical Specifications

• Product Type: Motor Management Relay
• Manufacturer: General Electric (GE)
• Model Number: 489-P1-LO-A20-E
• Relay Type: Low Voltage Motor Management Relay
• Nominal Voltage: 240V AC
• Nominal Current: 5A (CT secondary input)
• Frequency: 60 Hz
• Analog Current Input Supply: +24 V DC at 100 mA max
• Output/Neutral Current Conversion Range: 0.02 to 20 × CT
• Energy Metering Update Rate: 50 ms
• Voltage Phase Reversal Timing Accuracy: 200 to 400 ms
• IRIG-B DC Shift: TTL interface
• Ingress Protection: Complies with IEC60529 standard
• Dimensions: 3.5 cm x 13 cm x 13.5 cm
• Weight: 1.3 kg
