GE Multilin G60-U00-HKH-F8L-H67-M8L-P4D-U4D-W6C Generator Protection Relay

Overview

The GE Multilin G60-U00-HKH-F8L-H67-M8L-P4D-U4D-W6C is a generator protection relay. It protects medium and large generators. It ensures safe and efficient operation in power systems. The relay supports steam, gas, and hydro turbines.

Technical Specifications

• Model Number: G60-U00-HKH-F8L-H67-M8L-P4D-U4D-W6C
• Type: Generator Protection Relay
• Manufacturer: General Electric (GE)
• Application: Steam, gas, and hydro turbines
• Power Supply: 24V DC or 110-240V AC
• Relay Outputs: Configurable for control
• Communication Protocols: Modbus, DNP3, IEC 61850
• Data Logging: Event recording and fault analysis
• HMI: LCD display for real-time monitoring
• Operating Temperature: -40°C to +70°C
• Humidity: 10% to 95% RH, non-condensing
• Shock & Vibration: Complies with IEC 60068
• DCMA Input Type: Passive
• Generator Unbalance Pickup Level: 0.00 to 100.00%, steps of 0.01
• Nominal Frequency Setting: 25 to 60 Hz
• Phase Directional Overcurrent Angle Accuracy: ±2°
• Pollution Degree: II
• USB: 2.0 Type B
