GE Multilin G60E00HCLF8FH6PM8FP6CU6CW6C Generator Protection Relay

Overview

The GE Multilin G60E00HCLF8FH6PM8FP6CU6CW6C is a generator protection relay. It safeguards medium and large generators. The relay ensures safe, reliable, and efficient operation. It supports advanced monitoring, protection, and control functions for industrial power systems.

Technical Specifications

• Model Number: G60E00HCLF8FH6PM8FP6CU6CW6C
• Type: Generator Protection Relay
• Manufacturer: General Electric (GE)
• Application: Steam, gas, and hydro turbines
• Power Supply: 24V DC or 110-240V AC
• Protection Functions: Overcurrent, differential protection, loss of excitation, reverse power detection, voltage and frequency monitoring, synchronization checks
• Relay Outputs: Configurable for control applications
• Communication Protocols: Modbus, DNP3, IEC 61850
• Data Logging: Event recording and fault analysis
• HMI: LCD display for real-time monitoring
• Operating Temperature Range: -40°C to +70°C
• Humidity: 10% to 95% RH, non-condensing
• Shock & Vibration: IEC 60068 compliant
• AC Voltage Conversion Range: 1 to 275 V
• Breaker Failure Mode: 1-pole, 3-pole
• DCMA Input Type: Passive
• Ground Distance Directionality: All zones reversible
• Negative Sequence IOC Overreach: Less than 2%
• RTD Input Isolation: 36 V peak-to-peak
