Honeywell 10205/2/1 Fail-Safe Analog Output Module

Overview

The Honeywell 10205/2/1 is a fail-safe analog output module. It fits industrial automation and process control systems. It delivers high-precision signal processing and robust performance. The module supports efficient communication and ensures reliable operation.

Technical Specifications

• Product Type: Fail-safe analog output module
• Manufacturer: Honeywell
• Model Number: 10205/2/1
• Output Channels: 2, galvanically isolated from supply voltage
• Output Signal: Active or passive, 0–20 mA / 4–20 mA
• D/A Converter: 12-bit resolution
• Power Requirements:
  • 5 V DC at 30 mA
  • 24 V DC at 65 mA + 30 mA per active output
• Maximum Loop Resistance: 1 kΩ
• Maximum Output Voltage: 30 V DC (active loop powering)
• External Powering: Up to 40 V DC, minimum voltage drop 7.5 V
• Operating Temperature: Suitable for industrial environments
• Calibration: Potentiometers P2 and P3 for calibration
• Software Version: 3.00
• Space Requirements: 4 TE, 3 HE (4 HP, 3U)
• Dimensions: 325 mm × 150 mm × 150 mm
• ​Weight: 0.3kg
