Honeywell 900H32-0101 Digital Output Module Brand New

16 in stock

Manufacturer: Honeywell
Product No.: 900H32-0101
Country of origin: USA
Product Type: Industrial Automation
Condition: Brand New
Payment: T/T, Western Union
Weight: 0.227 kg
Dimensions: 137 × 35.6 × 137.16 mm
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

Product Overview

The Honeywell 900H32-0101 is a high-performance digital output module engineered for the ControlEdge HC900 system. It delivers 16 isolated output channels for precise and safe control of actuators, relays, solenoids, and other field devices. Moreover, the module’s robust design ensures reliable performance in demanding industrial environments, including process control, thermal management, and manufacturing automation. Its compact form factor supports flexible installation in space-constrained control panels.

Key Features and Benefits

Channel Isolation: Each output channel provides channel-to-channel and channel-to-chassis isolation for safe operation.
High-Speed Response: The module operates with a 6 ms ON/OFF response time, enabling real-time control of critical processes.
Hot-Swap Capability: Modules can be replaced without powering down the system, minimizing downtime.
Visual Status Indicators: LED indicators provide real-time feedback for rapid diagnostics and maintenance.
Overload Protection: Active current limiting with auto-recovery ensures system safety and reduces maintenance costs.
Flexible Mounting: Compatible with DIN rail or panel mount installations for diverse system configurations.

Technical Specifications

Parameter	Specification
Model Number	900H32-0101
Product Type	Digital Output Module
Controller Platform	Honeywell ControlEdge HC900
Channels	16 discrete outputs
Output Type	High-side driver (Current Sourcing)
Isolation	Galvanically isolated in 2 groups of 16 channels
Operating Voltage	10.5 to 32 VDC
Peak Voltage	32 VDC
Max Load Current (per point)	0.5 A (Resistive)
Max Load Current (per 8-ch group)	6 A (Resistive)
Max Load Current (per module)	12 A (Total, Resistive)
ON Voltage Drop	≤ 0.15 VDC at 0.5 A
Leakage Current	≤ 0.15 mA at 32 VDC
Response Time (ON/OFF)	6 ms
Overload Protection	Active current limiting; auto-recovery
Power Consumption (5V rail)	≤ 235 mA
Dimensions (H x W x D)	137 × 35.6 × 137.16 mm
Weight	0.5. lbs
Mounting	DIN rail or panel mount
Operating Temperature	-20°C to +60°C

Typical Applications

Process automation control and field device management
Thermal management systems requiring precise actuator control
Manufacturing automation including assembly lines and robotic integration
Industrial facilities requiring safe, isolated digital outputs

FAQ

Q1: Is the 900H32-0101 module hot-swappable? A1: Yes, the module supports hot-swapping, allowing replacement without system shutdown.

Q2: What type of isolation does this module provide? A2: It provides galvanic isolation for each channel, separated into two 16-channel groups.

Q3: What is the maximum load current per channel? A3: Each channel can handle up to 0.5 A resistive load.

Q4: Can it be mounted on a DIN rail? A4: Yes, the module supports both DIN rail and panel mounting.

Q5: What is the operating temperature range? A5: The module operates reliably from -20°C to +60°C.
