Honeywell CC-PAIH51 51410069-276 Analog Input Module High Quality

18 in stock

Manufacturer: Honeywell
Product No.: CC-PAIH51 51410069-276
Country of origin: USA
Product Type: Analog Input Module
Condition: Brand New
Payment: T/T, Western Union
Weight: 0.299 kg
Dimensions: 120 mm x 70 mm x 35 mm
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

Overview

The Honeywell CC-PAIH51 51410069-276 is an analog input module for Honeywell’s Experion Series-C I/O system. It converts analog signals from field devices into digital signals for processing and control. With HART communication support, it ensures precise and intelligent data acquisition.

Technical Specifications

General Information

Model Number: CC-PAIH51
Type: Analog Input Module with HART
Input / Output Model: CC-PAIH51 - High-Level Analog Input with HART
IOTA Models:
- CC-TAIX51: Non-Redundant (6”)
- CC-TAIX61: Redundant (12”)

Input Specifications

Channels: 16 single-ended analog input channels
Input Type: Analog current (2-wire or self-powered transmitters)
Input Range: 4 mA to 20 mA (through 200 Ω)
A/D Converter Resolution: 16 bits
Input Scan Rate: 50 ms

Performance Characteristics

Accuracy (@ CMV = 0 V):
- ±0.075% of full scale (23.5°C ± 2°C)
- ±0.15% of full scale (0°C to 60°C)
Common Mode Rejection Ratio (DC to 60 Hz, 500 Ω source imbalance): 70 dB
Common Mode Voltage (DC to 60 Hz): -6 V to +5 V peak
Normal Mode Rejection Ratio (at 60 Hz): 19 dB
Normal Mode Filter Response: Single-pole RC, -3 dB at 6.5 Hz
Maximum Normal Mode Input: ±30 V
Crosstalk (DC to 60 Hz, channel-to-channel): -60 dB

Power and Environmental Ratings

Power Supply: 24 VDC
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Dimensions: 120 mm x 70 mm x 35 mm (4.72 in x 2.76 in x 1.38 in)
Weight: 0.66 lbs
