Honeywell CC-SDRX01 I/O Link Interface Fiber Optic Converter

Overview

The Honeywell CC-SDRX01 is a fiber optic converter designed for I/O Link communication. It connects controllers with field devices like sensors and actuators. The device ensures fast, interference-free data transfer in demanding industrial environments. Its rugged build and ATEX/SAA certifications make it ideal for hazardous areas. Installers can easily mount it on a DIN rail. Use it in automation systems where long-distance and noise-resistant communication is essential.

Technical Specifications

• Model: Honeywell CC-SDRX01
• Type: I/O Link Interface Fiber Optic Converter
• Communication Interface: Fiber optic
• I/O Link: Yes, for controller-to-device communication
• Ports: 9 wired terminal connections
• Analog Output Module: Available on some models
• Power Supply: 24V DC
• Installation: DIN rail mounting
• Fiber Optic Distance: Up to 2 km (1.2 miles)
• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Storage Temperature: -55°C to +85°C (-67°F to +185°F)
• Humidity: 0% to 95% RH (non-condensing)
• Dimensions: 127 x 89 x 32 mm
• Weight: 1.00 lbs
