Honeywell FC-PSU-UNL2450U Power Supply Unit Brand New

Overview

The Honeywell FC-PSU-UNL2450U delivers stable and efficient power to automation systems. It meets industrial standards with high performance and durability.

Technical Specifications

Product Type: Power Supply Unit
Manufacturer: Honeywell
Model Number: FC-PSU-UNL2450U

Input and Output

• Input Voltage: Accepts 110–240V AC input
• Output Voltage: Provides 25V DC or 28V DC output
• Max Output Current: Delivers 48A at 25V DC and 43A at 28V DC
• Power Use at No Load: Consumes 13W with no connected load

Performance

• Efficiency: Achieves over 87% efficiency at 230V AC
• Ripple and Noise: Maintains output noise below 40mVpp
• Inrush Current: Limits inrush current to less than 15A
• Hold-up Time: Delivers a 100ms hold-up time at full load

Environmental Ratings

• Operating Temperature: Functions reliably from -5°C to +70°C
• Storage Temperature: Safely stores between -25°C and +85°C
