Description
The Honeywell FC-TSDO-04UNI is a high-performance universal digital output module designed for Honeywell’s Safety Manager system. It delivers reliable signal execution in safety-critical industrial environments, where consistent performance and fault tolerance are essential. With support for multiple output configurations, this module ensures flexible integration within SIL-rated safety systems. Moreover, its robust design and certified compliance make it ideal for oil and gas, chemical, and power generation industries.
Functional Highlights
The FC-TSDO-04UNI provides four isolated output channels for precise signal control. Each channel supports up to 2 A continuous current, ensuring stable performance in demanding applications. Its universal output capability allows operation with both standard and externally powered digital outputs. In addition, the module features screw terminal connections for secure field wiring and quick installation on DIN EN TS32 or TS35 rails.
Key benefits include:
- High reliability for Safety Integrity Level (SIL) systems
- Compact form factor for space-efficient installations
- Wide voltage range and strong electrical isolation
- Certified for CE, TUV, UL, CSA, and FM standards
- Designed and manufactured in the United States
Technical Specifications
| Specification | Details |
|---|---|
| Model | FC-TSDO-04UNI |
| Manufacturer | Honeywell |
| System | Safety Manager |
| Product Type | Universal Digital Output Module |
| Number of Channels | 4 |
| Maximum Voltage | 50 VDC (OV Category 3), 150 VDC (OV Category 2) |
| Max Continuous Current | 2 A per channel |
| Power Supply | Externally powered outputs supported |
| Dimensions | 60 × 70 × 54 mm (L × W × H) |
| Weight | 0.23 kg |
| DIN Rail Type | TS32 / TS35 × 7.5 |
| Used Rail Length | 61 mm (2.40 in) |
| Terminals | Screw terminal, max 2.5 mm² (AWG 14) |
| Strip Length | 7 mm (0.28 in) |
| Tightening Torque | 0.5 Nm (0.37 ft-lb) |
| Origin | United States |
Typical Applications
This module is widely used in safety and process control systems where output reliability is crucial. Typical applications include:
- Emergency shutdown systems (ESD)
- Burner management systems (BMS)
- Compressor and turbine safety controls
- Refinery and petrochemical process safeguarding
- Power generation control and interlock systems
Moreover, it integrates seamlessly with Honeywell Safety Manager controllers, providing accurate response and system-wide diagnostics for safer operations.
Support & Maintenance
Honeywell provides long-term technical support and spare part availability to ensure uninterrupted operation. The FC-TSDO-04UNI is designed for easy maintenance, with field-replaceable connections and diagnostic indicators that simplify troubleshooting. Regular firmware updates and calibration services help extend the lifecycle and maintain system compliance with safety standards.
FAQ
Q1: What is the main function of the Honeywell FC-TSDO-04UNI?
A1: It controls and executes digital output signals in Honeywell’s Safety Manager system for safety-critical operations.
Q2: How many channels does this module provide?
A2: The module offers four independent digital output channels.
Q3: Can it be used in SIL-rated safety systems?
A3: Yes, the FC-TSDO-04UNI fully supports SIL-rated applications requiring high integrity and reliability.
Q4: What mounting options are supported?
A4: It can be mounted on DIN EN TS32 or TS35 rails for flexible installation.
Q5: What certifications does it carry?
A5: It is certified by CE, TUV, UL, CSA, and FM, ensuring compliance with international safety standards.
