Honeywell XLS3000-CPUD Intelligent Addressable Fire Alarm Control Panel

Overview

The Honeywell XLS3000-CPUD is an intelligent addressable fire alarm control panel. It is built for medium to large-scale facilities that demand reliable fire detection and evacuation control. With support for advanced communication protocols and a large number of addressable devices, this panel ensures fast, accurate emergency response. Moreover, it is certified for mass notification and seismic environments, making it suitable for mission-critical applications.

Technical Specifications

• Product Type: Intelligent Addressable Fire Alarm Control Panel
• Manufacturer: Honeywell
• Model Number: XLS3000-CPUD
• Signaling Line Circuits (SLCs): Supports 1 to 10 isolated intelligent SLCs
• Device Capacity: Up to 3,180 intelligent addressable devices
• Display:
  • 16-line, 640-character backlit LCD display
  • Operates without display when used as a network node
• Event History:
  • 4,000-event nonvolatile memory log
  • 1,000-event alarm-only log
• Alarm Verification:
  • Selectable per point
  • Includes automatic counter
• Built-in Relays:
  • Alarm
  • Trouble
  • Security
  • Supervisory
• Communication Protocols:
  • Eclipse Detector Protocol
  • SWIFT Smart Wireless Integrated Fire Technology
• Certifications:
  • UL 2572 for Mass Notification (version 20 or higher)
  • Seismic-certified with proper mounting kit
• Environmental Conditions:
  • Standard industrial temperature range
  • High-humidity resistance
• Module: Fire Alarm Assembly Board
• Current Consumption: 0.12 AMP
• Weight: 2.91 lbs
