Ovation 5X00119G03 RTD Input Module Most Favorable

Overview

The Emerson Ovation 5X00119G03 is an RTD input module for the Ovation Distributed Control System (DCS). It enables accurate temperature sensing using Resistance Temperature Detectors (RTDs). This module integrates seamlessly into Ovation systems, supporting high-reliability industrial applications. Engineers value its precision, isolation features, and robust performance across varied environments.

Technical Specifications

• Product Type: Input Module
• Manufacturer: Emerson
• Model Number: 5X00119G03
• Input Type: RTD (Resistance Temperature Detector)
• Resolution: 12-bit
• Sampling Rate:
  • 50 Hz Mode: 16.67 samples/sec
  • 60 Hz Mode: 20 samples/sec
• Self-Calibration Mode: Initiated on demand by Ovation Controller
• Temperature Coefficient: 10 ppm/°C
• Dielectric Isolation:
  • Channel-to-Channel: 200V AC/DC
  • Channel-to-Logic: 1000V AC/DC
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Humidity: 0% to 95% RH (non-condensing)
