Phoenix Contact QUINT-PS-100-240AC/24DC/2,5 Power Supply

14 in stock

Manufacturer: Other PLC Module
Product No.: QUINT-PS-100-240AC/24DC/2,5
Country of origin: USA
Product Type: Power Supply
Condition: Brand New
Payment: T/T, Western Union
Weight: 1.179 kg
Dimensions: 42 mm × 168 mm × 37 mm
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

Overview

The QUINT-PS-100-240AC/24DC/2.5 is a high-performance, single-phase DIN rail-mounted power supply from Phoenix Contact. It delivers a stable 24 V DC output at 2.5 A, even under demanding industrial conditions. With POWER BOOST and preventive function monitoring, it starts heavy loads reliably. Additionally, it supports remote diagnostics, making it ideal for automation, process control, and machine-building applications.

Technical Specifications

Input Characteristics

Nominal Input Voltage: 100–240 V AC
Extended Input Range: 85–264 V AC / 90–350 V DC
Input Frequency: 45–65 Hz (AC), 0 Hz (DC)
Inrush Current: <20 A (typical)
Power Consumption: ~0.86 A @ 120 V AC, ~0.47 A @ 230 V AC
Internal Fuse: 5 A slow-blow
Transient Protection: Varistor-based
Mains Buffering Time: Ensures stable startup

Output Characteristics

Nominal Output Voltage: 24 V DC ±1%
Voltage Adjustment Range: 22.5–28.5 V DC
Nominal Output Current: 2.5 A (up to 60 °C)
POWER BOOST Current: 3.75 A (short-term)
Efficiency: >86%
Residual Ripple: <10 mVpp
Overvoltage Protection: ≤35 V DC
Feedback Voltage Resistance: 35 V DC
Capacitive Load: Unlimited
Rise Time: <2 ms
Control Deviation: <1% static, <2% dynamic, <0.1% input variation

Environmental & Mechanical

Operating Temperature: –25 °C to +70 °C
Derating: 2.5%/K above 60 °C
Mounting: DIN rail
Protection Class: IP20
Cooling: Convection

Key Features

Protection: Short-circuit, open-circuit, overvoltage, thermal
MTBF: >500,000 h at 40 °C
Connection Method: Screw connections
