Siemens G34924-K2200-H1 SIMATIC S7 DP Timer Module

Overview

The Siemens G34924-K2200-H1 is a dedicated DP timer module engineered for SIMATIC S7 automation platforms. Designed to operate within PROFIBUS-DP networks, this module delivers reliable, deterministic timing functions required for distributed control tasks in industrial environments. Its compact design and low power consumption make it suitable for control cabinets where efficiency and space optimization are critical.

Key Functional Capabilities

This module provides hardware-based timing functionality, allowing timing operations to be handled independently of the main CPU cycle. By offloading timing tasks, the system can achieve improved response consistency and reduced CPU load in PROFIBUS-DP architectures.

Typical functions include delay control, time-based triggering, and synchronization support for distributed I/O stations.

Technical Specifications

• Operating Voltage: 24 VDC
• Rated Current Consumption: Approx. 150 mA
• Communication Interface: PROFIBUS-DP
• System Compatibility: Siemens SIMATIC S7 series
• Module Category: DP Timer Module
• Installation: Distributed I/O / S7 modular systems

Mechanical and Physical Characteristics

• Form Factor: Compact S7 DP module design
• ​Weight: 1.98 lbs
• Mounting: Standard SIMATIC S7 rail-mounted configuration

Note: Some marketplace listings reference incorrect weight data. Based on Siemens-style DP modules of this class, the realistic weight is approximately 0.1 kg rather than multi-pound values.

System Compatibility

The G34924-K2200-H1 integrates seamlessly with SIMATIC S7 controllers and PROFIBUS-DP networks. It is intended for use in distributed automation architectures where precise and repeatable timing behavior is required at the field level.

Typical Application Scenarios

This module is commonly used in conveyor systems, packaging lines, material handling equipment, and process automation where deterministic timing control is essential. It is well-suited for plants using PROFIBUS-DP as a standardized fieldbus.

Ordering and Commercial Notes

• Model / Part Number: G34924-K2200-H1
• Alternate Reference: G34924K2200H1
• Market Availability: New surplus, refurbished, or pre-owned depending on supplier inventory

FAQ

What is the primary role of this DP timer module?

It provides dedicated timing functions within a PROFIBUS-DP system, reducing reliance on PLC software timers and improving timing accuracy.

Is this module compatible with all SIMATIC S7 CPUs?

It is designed for SIMATIC S7 environments that support PROFIBUS-DP. Compatibility should be confirmed against the specific S7 rack and DP configuration.

Does the module require high power input?

No. The module operates at 24 VDC with a relatively low current requirement of approximately 150 mA, making it suitable for standard S7 power supplies.
