Woodward 5466-1145 CPU5200 Cyber Security Controller

​Overview

The Woodward 5466-1145 is a cyber-hardened CPU5200 main controller developed for the MicroNet Plus digital control platform. Designed for mission-critical rotating equipment, this controller combines deterministic real-time performance with an embedded cybersecurity framework suitable for regulated industrial environments.

This unit supports both simplex and fully redundant control architectures and is commonly deployed as the primary processor in turbine, engine, and compressor control systems where availability, safety, and secure communications are mandatory.

Controller Function and System Role

Within a MicroNet Plus control rack, the CPU5200 Cyber Security Unit operates as the central execution and coordination module. It manages control logic, I/O data processing, network communications, and system diagnostics.

In redundant configurations, the controller operates in parallel with a second CPU installed in the CPU2 slot, enabling fault-tolerant operation with automatic role arbitration and seamless switchover.

Cyber Security Architecture

The 5466-1145 variant is delivered with a licensed cyber-security feature set that aligns with modern critical-infrastructure protection standards.

Key security characteristics include:

Secure implementation of VxWorks RTOS 6.8 with hardened services Encrypted communication using Secure Shell (SSH) Role-based user authentication and password control mechanisms Embedded firewall functions to restrict unauthorized access Updated GAP security function blocks and protocol toolsets Designed to support NERC CIP-aligned system deployments

This architecture ensures deterministic control performance without compromising security posture.

Environmental and Mechanical Characteristics

The controller is engineered for continuous operation in demanding industrial installations, including turbine enclosures and offshore or remote facilities.

Operating temperature range from –40 °C to +85 °C Designed for long-term reliability under thermal and electrical stress Shock resistance compliant with US MIL-STD-810C Suitable for Class I, Division 2 hazardous locations (North America)

Compliance and Certification

North American CSA Class I Division 2 approval EAC Customs Union compliance for European and Eurasian markets Industrial-grade design aligned with power generation and oil & gas standards

Typical Applications

Gas turbine control systems Steam turbine governing and protection Hydro turbine automation Diesel and gas engine management Compressor and mechanical drive control Cyber-secured modernization of legacy MicroNet systems

Technical Specifications

Operating System: Secure VxWorks RTOS 6.8 Controller Type: CPU5200 Cyber Security Licensed Control Architecture: Simplex or Redundant Manufacturer: Woodward Temperature Rating: –40 °C to +85 °C Shock Standard: US MIL-STD-810C Regulatory Approval: CSA Class I Div 2, EAC Documentation Reference: Technical Manual 26166 (Three-Volume Set)

FAQ

Can the 5466-1145 be used in non-redundant systems? Yes. The controller fully supports simplex installations and can later be expanded to redundant architectures.

Is this controller compatible with standard MicroNet Plus I/O modules? Yes. It is designed for full compatibility with MicroNet Plus racks, RTN networks, and supported I/O families.

Does this unit require additional licensing for cybersecurity features? No. The cyber-security functionality is factory-licensed and enabled on the 5466-1145.
