Product Description
The ADV551-P63/D5A00 digital output module is engineered for dependable ON/OFF control within Yokogawa distributed control architectures. Designed for the FIO (Field Input/Output) platform, this module delivers stable 24 V DC signals to field actuators and interface devices while maintaining electrical isolation between channels and system electronics.
Its compact mechanical design and support for redundant system configurations make it well suited for high-availability control cabinets in continuous process operations.
Integrated seamlessly into CENTUM VP and CS 3000 systems, the ADV551-P63/D5A00 ensures predictable switching behavior, fast output response, and long-term operational stability under industrial environmental conditions.
Key Technical Specifications
- 32 independent digital output channels
- Rated output voltage: 24 V DC
- Output type: Isolated per channel group
- Compatible with Yokogawa FIO I/O nodes
- Supports system redundancy configurations
- Short switching response suitable for interlock and sequence control
- Compact housing optimized for high-density I/O racks
- Weight: 0.2 kg
System Compatibility
- Yokogawa CENTUM VP Distributed Control System
- Yokogawa CS 3000 Distributed Control System
- FIO field I/O architecture with standard backplane mounting
Applications
- Actuation of solenoid valves and motor starters
- Relay driving for alarms and interlocks
- Control of indicator lamps and status beacons
- Digital control loops in chemical, oil & gas, power, and utilities
FAQ
Q: Does this module support redundant control systems?
Yes. The ADV551-P63/D5A00 is designed for use in redundant FIO configurations to enhance system availability.
Q: Are the outputs electrically isolated?
Yes. Output channels are isolated to minimize noise coupling and protect control electronics from field-side disturbances.
Q: What type of loads can be driven?
The module is suitable for standard 24 V DC loads such as relays, solenoids, and panel indicators within specified current limits.
