Overview
The Yokogawa AIP571/S1 is a high-density analog input module engineered for CENTUM VP Distributed Control Systems (DCS). It acquires analog signals from field instruments such as temperature, pressure, flow, and level transmitters and converts them into precise digital data for reliable process monitoring and control. The module supports multiple input types and is built for harsh industrial environments with robust noise immunity and diagnostic capabilities.
Key Features
- High-density input: 16 isolated analog input channels in a compact module
- Universal signal compatibility: Supports 4–20 mA, 1–5 V, thermocouple, and RTD signals
- Noise-resistant: Stable operation in electrically noisy environments
- Built-in diagnostics: Wire break detection and self-test functionality
- Flexible integration: Compatible with ESB and Optical ESB bus node units
- Compact design: Space-saving for modular panel installation
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AIP571/S1 |
| Module Type | Analog Input Module |
| Number of Channels | 16 isolated analog input channels |
| Supported Signals | 4–20 mA DC, 1–5 V DC, Thermocouple, RTD (depending on configuration) |
| Input Range | Configurable per channel |
| Accuracy | ±0.1% of span (typical) |
| Resolution | 16-bit A/D conversion |
| Isolation | Channel-to-channel and channel-to-system isolation |
| Response Time | Typical 100 ms |
| Diagnostics | Input circuit self-check, wire break detection |
| Dimensions | 107.5 × 130 × 32.8 mm |
| Weight | 0.3 kg |
| Mounting | DIN rail or module rack |
| Operating Temperature | -10°C to +60°C |
| Humidity Range | 5%–95% RH (non-condensing) |
Applications
- Acquisition of temperature, pressure, flow, and level signals in process control systems
- Monitoring in chemical, oil & gas, power generation, and manufacturing environments
- High-reliability analog input for safety and industrial monitoring systems
FAQ
Q: What types of field instruments are supported?
A: Thermocouples, RTDs, 4–20 mA DC, and 1–5 V DC input signals.
Q: Can each channel be configured independently?
A: Yes, each channel can be set with a unique input type and range.
Q: Is the module suitable for high-noise industrial environments?
A: Yes, it is designed with strong EMI resistance for stable operation.
Q: Can it integrate with fiber-optic ESB systems?
A: Fully compatible with Yokogawa ESB and Optical ESB bus node units.
Q: How does it differ from similar models like AIP571/S2?
A: The S1 offers standard 16-channel isolated inputs, while S2 may provide enhanced redundancy and extended diagnostics.
