Overview
The Woodward easYgen-3500XT (8440-2179) is a high-performance generator controller engineered for complex industrial, marine, and critical backup power applications. It provides comprehensive control, synchronization, and monitoring for multiple generator sets, ensuring reliable operation in extreme environmental conditions. Designed for system integrators and industrial power engineers, this controller supports advanced parallel operation with flexible communication interfaces for modern SCADA integration.
Technical Specifications
| Feature | Specification |
|---|---|
| Power Supply | 24 VDC |
| Operating Temperature | –40 °C to +70 °C |
| Weight | 3.5 kg |
| Supported Frequency | 40–85 Hz (compatible with 50/60 Hz systems) |
| Voltage Measurement Range | 50–650 V AC |
| Current Measurement | 1 A / 5 A |
| Relay Outputs | Fully isolated, configurable |
| Digital Inputs/Outputs | Multiple programmable channels |
| Communication Interfaces | USB, RS-485 (Modbus RTU Slave), CANopen |
| Control Modes | AUTO, MANUAL, STOP, TEST |
| Maximum Gensets in Parallel | Up to 32 units |
| Housing | Rugged sheet metal enclosure |
Key Features
- Multi-Genset Operation: Simultaneous control of up to 32 generators with automatic sequencing.
- Precision Synchronization: Advanced load sharing and breaker management capabilities.
- Robust Environment Tolerance: Operates reliably across a wide temperature range from –40 °C to +70 °C.
- Flexible Connectivity: Supports USB, RS-485, and CANopen for SCADA or monitoring integration.
- Industrial Durability: Ruggedized enclosure and isolated outputs provide long-term operational reliability.
Applications
- Industrial power generation facilities
- Marine propulsion and shipboard power systems
- Emergency backup and critical infrastructure
- Distributed energy systems requiring multi-genset coordination
FAQ
Q: Can the easYgen-3500XT handle multiple generators in parallel? A: Yes, it supports up to 32 gensets with automated sequencing and load sharing.
Q: Does it include a built-in display? A: No, monitoring is typically performed via external panels or SCADA systems.
Q: What communication protocols are supported? A: USB, RS-485 (Modbus RTU Slave), and CANopen for flexible integration.
Q: How rugged is the device? A: The unit operates from –40 °C to +70 °C and has a durable sheet metal housing with isolated outputs for industrial-grade reliability.
