FOXBORO 900701-10-02 Fast Ethernet Switch Module

Overview

The FOXBORO 900701-10-02 is a high-performance Fast Ethernet Switch Module. It serves industrial automation and control systems, providing high-density network connectivity. Therefore, it suits mission-critical applications that demand reliability, scalability, and flexible management. Moreover, it supports Power over Ethernet (PoE) and offers a stackable design for large-scale deployments in manufacturing plants, energy facilities, and process control networks.

Technical Specifications

Model Number: 900701-10-02 Product Type: Fast Ethernet Switch Module Manufacturer: FOXBORO

Network Interfaces:

• Ethernet Ports: 48 × 10/100 Mbps RJ45
• SFP Uplink Slots: 2 × SFP (Ports 51 & 52)
• Stacking Ports: 2 × 1000BASE-T RJ45 (Ports 49 & 50)

PoE Support:

• Standard: IEEE 802.3af
• Power per Port: Up to 15.4 W
• Total PoE Budget: 360 W

Uplink Compatibility:

• MGBIC-LC01, LC03, LC09, MT01

Supported Standards:

• IEEE 802.3, 802.3u, 802.3ab, 802.3ad, 802.3af, 802.3z

Power Supply:

• Internal, with optional redundant supply via C2RPS-POE

Management Interfaces:

• WebView GUI, CLI, SNMP

Stacking Capability:

• Up to 8 A2 switches

Environmental Specifications:

• Operating Temperature: 0 to 60°C (32 to 140°F)
• Storage Temperature: -40 to 85°C (-40 to 185°F)
• Humidity: 5 to 95% relative humidity, non-condensing

Physical Characteristics:

• Weight: 2.81 kg
