Honeywell 9202-ETS-TR1 Hardened Industrial Security Appliance

Overview

The Honeywell 9202-ETS-TR1 is a hardened industrial security appliance. It protects SCADA and process control networks from cyber threats. This appliance enforces advanced firewall rules and secures critical data flow. With multiple interface options and protocol-specific security modules, it integrates seamlessly into existing industrial environments. Moreover, it withstands extreme conditions, making it ideal for harsh installations.

Technical Specifications

General

• Manufacturer: Honeywell
• Model: 9202-ETS-TR1
• Function: Cybersecurity for SCADA/process networks

Ethernet Interfaces

• Net 1: 100BASE-TX (Copper)
• Net 2: 100BASE-TX (Copper)

Additional Interfaces

• USB Port: 1 x USB socket (for configuration)
• Digital Input: 1 x 2-pin plug-in terminal block
• Signaling Contact: Up to 60V DC or 30V AC, SELV, max. 1A

Network Size

• Twisted Pair (TP): 0–100 meters
• Multimode Fiber (MM): 0–5000 meters (50/125 μm)
• Singlemode Fiber (SM): 0–30 kilometers (9/125 μm)

Power Requirements

• Operating Voltage: 12–48V DC, 24V AC (redundant input supported)
• Power Consumption: 5 Watts

Software & Security

• Management Tool: MTL Tofino Configurator (TC)
• Pre-installed Modules:
  • Firewall
  • Event Logger
  • NetConnect

Environmental Conditions

• Operating Temperature: -40°C to +70°C
