Honeywell FC-IOCHAS-0002S Quad Digital input/Output (I/O) Module

Overview

The Honeywell FC-IOCHAS-0002S is a quad digital input/output (I/O) module that is used in safety applications. It has four isolated inputs and four isolated outputs, and it can be used to monitor and control safety-critical devices. The module is compliant with IEC 61508 SIL 3 and IEC 62061 SIL CL3 standards.

Features

• Four isolated inputs
• Four isolated outputs
• SIL 3/CL3 compliant
• 24 VDC power supply
• Modbus RTU communication
• DIN rail mounting

Technical Specifications

• Input voltage range: 24 VDC
• Input current: 20 mA
• Output voltage: 24 VDC
• Output current: 200 mA
• Communication speed: 9600 baud

FC-IOCHAS-0002S and IOCHAS-0002S

FC-IOCHAS-0002S and IOCHAS-0002S are both I/O modules produced by Honeywell, but there are some key differences between them. FC-IOCHAS-0002S is a quad digital I/O module, supporting 4 digital inputs and 4 digital outputs. IOCHAS-0002S is a chassis that can accommodate up to 18 non-redundant I/O modules, including digital inputs, digital outputs, analog inputs, and analog outputs. As a result, FC-IOCHAS-0002S is a smaller, simpler module, while IOCHAS-0002S is a larger, more versatile chassis. Here is a detailed comparison of the two modules:

Feature	FC-IOCHAS-0002S	IOCHAS-0002S
Type	Quad digital I/O module	Rack-mounted I/O module
Supported inputs	4 digital inputs	A variety of inputs, including digital inputs, digital outputs, analog inputs, and analog outputs
Supported outputs	4 digital outputs	A variety of outputs, including digital inputs, digital outputs, analog inputs, and analog outputs
Dimensions	100 mm x 50 mm x 25 mm	220 mm x 170 mm x 110 mm
Weight	0.2 kg	2.5 kg
Price	About $200	About $500

Ultimately, the module you choose will depend on your specific needs. If you need a small, simple module to add I/O inputs and outputs, FC-IOCHAS-0002S is a good option. If you need a larger, more versatile chassis to support a variety of I/O types, IOCHAS-0002S is a better choice.
