Yokogawa SAI143-H03 Analog Input module (Current input)

Model SAI143 Analog Input Module:

• Input Type: 4 to 20 mA
• Number of Channels: 16 channels
• Module Isolation: Yes
• HART Communication: Available with the "H" suffix code

Suffix Codes:

• -S: Standard type
• -H: With HART communication (Release: R1.02.00)
• -5: For pressure clamp terminal block or MIL cable with no explosion protection
• -6: With signal cable interface adapter and no explosion protection
• -E: For pressure clamp terminal block or MIL cable with explosion protection
• -F: With signal cable interface adapter and explosion protection
• -3: With ISA Standard G3 and temperature (-20 to 70 ºC)
• -C: With ISA Standard G3 and high-density installation (-20 to 70 ºC)

Option Codes:

• /A4S00: With pressure clamp terminal block for analog
• /A4S10: With pressure clamp terminal block for analog (with surge absorber)
• /A4D00: With dual-redundant pressure clamp terminal block for analog
• /A4D10: With dual-redundant pressure clamp terminal block for analog (with surge absorber)
• /PRP: With prevention pin of false insertion
• /CCC01: With connector cover for MIL cable (for flat ribbon cable)

Additional Notes:

• For dual-redundant pressure clamp terminal block, do not use suffix codes S1.
• When selecting suffix codes -6 or -F, you cannot choose the option code for pressure clamp terminal block and MIL cable connector.
• When using this module in a dual-redundant configuration, order an additional module with the same specifications but without option codes.
• If suffix codes -6 or -F are selected, you can choose the option code for prevention pin of false insertion.
• A mechanism to prevent the wrong type of I/O module insertion is supported with a signal cable. The signal cable used with this I/O module must have the option code /SAI143.
• The suffix code for "With ISA Standard G3 and high-density installation" is available for SAI143-HC. This is not available for SAI143-S.

Download YokogawaSAI143-H03 PDF Manual：GS32Q06K30-31E
