Yokogawa SDV541-S13 Digital Output Module Brand new in Stock

Model:

SDV541-S13 Digital Output Module (16-channel, 24 V DC, module isolation)

Item Specifications:

• Number of Outputs: 16-channel, module isolation (*3)
• Output Voltage: 24 V DC
• Output Voltage Drop: 1 V maximum
• External Power Supply Rating: 24 V DC, 3.4 A minimum
• External Power Supply: 24 V DC + 20 % / -10 % (*4), Current capacity: 3.4 A
• Maximum Leak Current at Output Off Status: 1.6 mA
• Output Format: Current source
• Maximum Load Current: 0.2 A/output line (3.2 A in total output line) (*3) (*5)
• Minimum Load Current: 35 mA
• Load Resistance Range: 120 to 685 Ω (*6)
• Output Response Time: 30 ms maximum
• Withstand Voltage (*1) (*2): 2 kV AC between output signal lines and system for 1 minute, 16-point input lines collectively connected (negative lines) (*7)
• Current Consumption: 300 mA maximum (5 V DC), 150 mA maximum (24 V DC)
• Weight: Approx. 0.29 kg (For pressure clamp terminal block or MIL cable), Approx. 0.31 kg (With dedicated signal cable interface adapter)
• External Connection: Pressure clamp terminal, MIL cable, Dedicated signal cable (AKB331, AKB651)

NOTE：

*1: These voltages show the case using the field power supply floating. When the field power supply is grounded, the system (functional) ground is connected to the field ground, which is not isolated. For higher noise immunity, floating the field power supply is recommended.

*2: When the withstanding voltage of the field power supply between the secondary side and the ground is lower than the value shown in the table above, these voltages are adopted as the withstanding voltage of the field power supply.

*3: Number of output channels that a user can use and maximum load current are restricted in case of SDV541-SC. Refer to “ProSafe-RS Outline of I/O Modules (for FIO)” (GS 32P06K60-01EN). *4: External power supply of SDV541 style code S1 is 24 V DC ± 5%.

*5: Do not exceed this value, including the case of inrush/variation of the load current.

*6: Resistance value of the load for both ON and OFF state, including the field wiring resistance.

*7: When connecting SDV541 and SED4D terminal board using AKB331 dedicated signal cable, the withstand voltage is 500 V AC (between output signal lines and system).

If MIL connector cables are used, the withstand voltage depends on their cable’s electrical specifications.

The Yokogawa SDV541 Digital Output Module comes with various suffix codes and option codes, allowing for customization based on specific requirements:

Suffix Codes:

• -S: Standard type
• 5: For pressure clamp terminal block or MIL cable with no explosion protection
• 6: With signal cable interface adapter and no explosion protection
• E: For pressure clamp terminal block or MIL cable with explosion protection
• F: With signal cable interface adapter and explosion protection
• 3: With ISA Standard G3 and temperature (-20 to 70 °C)
• C: With ISA Standard G3 and high-density installation (-20 to 70 ºC)

Option Codes:

• /B4S00: With pressure clamp terminal block for digital output (without surge absorber)
• /B4S10: With pressure clamp terminal block for digital output (with surge absorber)
• /B4D00: With dual-redundant pressure clamp terminal block for digital output (without surge absorber)
• /B4D10: With dual-redundant pressure clamp terminal block for digital output (with surge absorber)
• /PRP: With prevention pin of false insertion
• /CCC01: With connector cover for MIL cable (for flat ribbon cable)
• /CCC02: With connector cover for MIL cable (for discrete wire cable)

Please note the restrictions and considerations mentioned for specific suffix codes and option codes, as indicated in the description. For example, when selecting SDV541-S6 or -SF, certain option codes for pressure clamp terminal block and MIL cable connector are not available, and a mechanism to prevent wrong type I/O module insertion is supported with signal cable with specific option codes.
