ABB 3BHE028761R1001 GDC806A1001 karta distribuovaného řídicího systému

The ABB GDC806A1001 (3BHE028761R1001), also cataloged as the GDC806A1001 Gate Drive and Communication Processor Module, executes gate signal processing and communication functions for power semiconductor control. It uses an Intel Atom E3845 quad-core processor and interfaces with 24 VDC supply, 5 VDC input signals, and CAN, Modbus, with ProfiNet listed as optional.

Hardware Specifications

Gate Drive and Communication Processing

The GDC806A1001 combines processor-based communication handling with gate-drive signal processing for power semiconductor control. The Intel Atom E3845 quad-core processor operates at 1.92 GHz and provides the computational platform for communication and real-time control tasks.

The module accepts 5 VDC input signals and provides a maximum stated output current of 5 A. The specified gate-drive response time is less than 5 microseconds. CAN and Modbus communication are listed as standard interfaces, while ProfiNet is identified as an optional interface.

The module specifies 2500 VDC isolation voltage between electrically isolated sections. This isolation must be maintained during wiring and system integration according to the applicable ABB hardware documentation.

Frequently Asked Questions (FAQ)

Q: What supply voltage does the GDC806A1001 require?
A: The supplied specification identifies a 24 VDC supply voltage.

Q: What processor is installed on the GDC806A1001?
A: The module uses an Intel Atom E3845 quad-core processor operating at 1.92 GHz.

Q: Which communication interfaces are specified?
A: CAN and Modbus are specified, with ProfiNet listed as an optional communication interface.

Field Installation Guidelines

• Verify the module part number, GDC806A1001 designation, and 3BHE028761R1001 identification before installation.
• Confirm the 24 VDC supply polarity and electrical characteristics before energizing the module.
• Keep 5 VDC signal wiring separated from high-current switching and power semiconductor conductors where practical.
• Route communication wiring according to the applicable CAN, Modbus, or ProfiNet physical-layer requirements.
• Maintain the specified isolation boundaries and do not bypass galvanic isolation through unintended cable shields, bonding paths, or auxiliary wiring.
• Connect cable shields and protective earth according to the system grounding design and ABB installation documentation.
• Provide mechanical support appropriate for the approximately 120 mm x 100 mm x 25 mm module dimensions.
• Verify connector engagement and wiring continuity before applying power or connecting the module to gate-drive circuitry.
• Do not substitute communication interfaces or firmware configurations without confirming compatibility with the installed control system.
