ABB GJR2368900R2340 87TSO11-E Coupler Module In Stock

Overview:

The ABB GJR2393200R1210 88TK05D-E Station Bus Coupling Module is designed for integration within PROCONTROL cabinets, serving as the passive component of the bus coupling system. Here are its key features and technical specifications:

Key Features:

• Bus Connection:
  • Connects to the bus via incoming and outgoing twin-axial cables.
• Station Connection:
  • Interfaces with the station using a 25-pin D-type connector.
• Galvanic Isolation:
  • Provides isolation between the bus and the station, enhancing safety and reliability.
• Redundancy Support:
  • Supports redundant station operation for increased system reliability.
• Standard Compliance:
  • Complies with PROFIBUS DP standard, ensuring compatibility with other devices.

Technical Specifications:

• Bus Type: PROFIBUS DP
• Data Rate: 1.5 Mbps
• Baud Rate: 9600 bps
• Cable Length: Up to 1,200 meters (3,937 feet)
• Power Supply: 24 VDC
• Power Consumption: 2 W
• Operating Temperature: -20 to +60 °C (-4 to +140 °F)
• Storage Temperature: -40 to +80 °C (-40 to +176 °F)
• Humidity: 0 to 95% RH (non-condensing)
• Protection: IP20 (protected against solid objects > 12 mm, no protection against water)

Applications:

The ABB GJR2393200R1210 88TK05D-E is commonly used in various applications including:

• Process control systems
• Manufacturing automation
• Building automation
• Power distribution
