YOKOGAWA ADV569 Digital Output Module High Quality

16 in stock

Manufacturer: Yokogawa
Product No.: ADV569
Product Type: Digital Output Module
Condition: Brand New
Payment: T/T, Western Union
Weight: 0.3 kg
Dimensions: 144 x 100 x 30 mm
Shipping port: Xiamen
Warranty: 12 months

Description
Reviews
Shipping & Payment

Overview

The Yokogawa ADV569 is a digital output module within the CENTUM-ST series, designed for use in industrial automation systems. It provides 64 output channels and supports a variety of input and output signal types, making it ideal for applications that require precise control and fast response times. The module is compatible with ST7 cards and is designed for efficient operation with minimal current consumption.

Technical Specifications

Model: Yokogawa ADV569
Number of I/O Channels: 64 digital output channels
Signal Isolation: Common every 16 channels
Input Signal Type: Transistor contact (supports both inductive and resistive loads)
Input Contact Rating: 30V DC, 100 mA
Pushbutton Input Function: Supported
Input Response Time: 16 ms or less
Output Signal Type: Transistor contact
Output Contact Rating: 30V DC, 100 mA
Output Response Time: 8 ms (plus up to 1 ms delay for ON/OFF)
Pulse Width: Adjustable from 8 ms to 7200 s
Pulse Width Resolution: 1 ms
Maximum Current Consumption: 800 mA (5V DC)
Weight: Approximately 0.30 kg
External Connection: Dedicated cable (KS9)
Compatible Card: ST7 compatible
